LUX
Using the most sophisticated technology, LUX delivers a superior design with a higher resolution than ever before! The perfect harmony and transition between visual fields allows the wearer generous areas for both distance and near with a wider and more lucid intermediate. LUX can account for the patient’s near pupillary distance in order to position the correct inset based on the prescription for both distance and near vision. LUX progressive lenses are available in almost all materials with five different corridor lengths of 7,8,9,10 and 11 mm312.
Power Map
Cylinder Map
 |
CORRIDOR LENGTH (CL): | 7/8/9/10/11 MM |
| NEAR REFERENCE POINT (Npy): | 10/11/12/13/14 MM | |
| FITTING HEIGHT: | 15/16/17/18/19 MM | |
| INSET: | 2.5 MM | |
| DECENTERATION UP TO 10MM AT MAX. DIA. 80 MM | ||
| DEFAULT WRAP: | 5 DEGREE | |
| DEFAULT TILT: | 7 DEGREE | |
| BACK VERTEX: | 12 MM | |
| CUSTOMIZE: | YES | |
| WRAP SUPPORT: | YES | |
| ATORICAL OPTIMIZATION: | YES | |
| FRAME SELECTION: | YES | |
| ADDITION: | 0.5 – 5.00 DPT. | |
| APPLICATION: | UNIVERSAL | |
